3v 6v brush motor with 16mm gearbox

3v 6v brush motor with 16mm gearbox
Model No. : DSD-16RS050
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 500pcs
Typical applications: auto shutter, binding machine, automatic TV rack, money counter, spot light, tissue machine, office equipments, household appliances, automatic actuator...

PDF Download

DSD-16RS050 3v 6v brush motor with 16mm gearbox

Drawing (mm)
Remark: find the length of gearbox "L" in below Technical Data of Gearbox.

Configurations
Below configurations are for reference only. Contact us for more.
Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
DSD-16RS0500057000-130K 5V 53 ≤100 41 ≤350 0.8 0.34 ≥650 3
DSD-16RS0500068000-65K 6V 123 ≤80 106 ≤330 0.3 0.33 ≥674 1.2
DSD-16RS0500068000-365K 6V 22 ≤100 17 ≤400 1.9 0.33 ≥730 6
DSD-16RS05000612000-91K 6V 132 ≤150 94 ≤500 0.5 0.48 ≥850 1.6
DSD-16RS05000914000-631K 9V 22 ≤140 19 ≤260 2.2 0.43 ≥340 6
DSD-16RS05001215000-40K 12V 375 ≤50 303 ≤250 0.2 0.62 ≥290 1
DSD-16RS0500128000-112K 12V 71 ≤40 52 ≤100 0.34 0.18 ≥170 1
DSD-16RS0500128000-448K 12V 17 ≤40 13 ≤90 0.9 0.12 ≥150 2.8
DSD-16RS0500128000-515K 12V 15 ≤50 12 ≤100 0.97 0.12 ≥160 3
DSD-16RS05001210500-515K 12V 20 ≤45 12 ≤150 1.6 0.20 ≥310 6
DSD-16RS0500128000-631K 12V 12 ≤45 8 ≤90 1.4 0.11 ≥130 3.5
DSD-16RS05001216000-889K 12V 18 ≤100 13.8 ≤190 2 0.28 ≥210 5
DSD-16RS05002416000-112K 24V 142 ≤40 118 ≤135 0.5 0.61 ≥327 2
DSD-16RS05002416000-159K 24V 100 ≤60 80 ≤230 0.7 0.57 ≥300 2.6
DSD-16RS05002416000-257K 24V 62 ≤75 45 ≤200 1.3 0.60 ≥300 3.9
DSD-16RS05002416000-315K 24V 51 ≤75 38 ≤200 1.6 0.62 ≥300 4.6
DSD-16RS05002416000-365K 24V 44 ≤75 34 ≤180 1.4 0.49 ≥300 5
DSD-16RS05002416000-889K 24V 18 ≤75 14 ≤160 3 0.43 ≥300 6

What a Model Number Tells You?
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.

Technical Data of Gearbox
Reduction Stage 3 4 5 6 7
Reduction Ratio 10K, 14K 23K, 28K, 32K, 40K 46K, 56K, 65K, 79K, 91K, 112K 130K, 159K, 183K, 224K, 257K, 315K 365K, 448K, 515K, 631K, 725K, 889K
Length of Gearbox "L" mm 11 12.5 14 15.5 17
Gearbox Efficiency 73% 65% 59% 53% 48%

Technical Data of Motor
Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA rpm mA rpm gf.cm W gf.cm mA
DSD-0500068000 6 ≤65 8000 ≤200 6500 7.5 0.50 36 ≥500
DSD-05000612000 6 ≤75 12000 ≤300 9300 10 0.97 40 ≥1000
DSD-0500098000 9 ≤50 8000 ≤150 6500 7 0.47 33 ≥360
DSD-0500128000 12 ≤35 8000 ≤110 6500 6.5 0.44 31 ≥170
DSD-05001217900 12 ≤68<, /TD> 17900 ≤300 12800 12 1.58 54 ≥1260

DIY with Your Gear Motor
With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.
