DS-380 28mm 7.2 Volt and 12 Volt Electrical DC Motor

DS-380 28mm 7.2 Volt and 12 Volt Electrical DC Motor
Model No. : DS-380
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 5000pcs ...

PDF Download

DS-380 28mm 7.2 Volt and 12 Volt Electrical DC Motor

Drawing (mm)

Specifications
Specifications below are for reference only. Contact us for more.
Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA gf.cm W mA gf.cm
DS-380-7.2-16200 7.2V 16200 500 14000 3290 110 15.80 21600 840
DS-380-009-13000 9V 13000 370 10900 2080 90 10.07 7220 480
DS-380-009-17000 9V 17000 680 13800 4600 130 18.41 13200 550
DS-380-012-6300 12V 6300 150 5600 600 70 4.02 1860 340
DS-380-012-15200 12V 15200 340 13150 2180 128 17.3 14000 949
DS-380-024-8000 24V 8000 70 6540 310 63.9 4.29 1400 350
Remark: 1 gf.cm0.098 mN.m0.014 oz.in    1 mm0.039 in

FAQs
Q: Can you make a motor with custom specifications?
A: Yes, we can and we welcome that.
Q: What is delivery time of sample?
A: One week or two if it is with regular specifications. If not, it takes 3 weeks or even one month.
Q: What is delivery time of mass production?
A: Normally it is around one month. It may take longer time if it is in large quantity or other special situations.
Q: What is your MOQ (minimum order quantity)?
A: You can find it in the front of the product page.
Q: Do we have motors in stock?
A: No, we don’t. All motors are made with orders.
Q: How to pay you?
A: a) We prefer PayPal payment for samples and small amount of money. b) T/T for big orders. Regular payment terms: 30% or 50% deposit, balance before shipment / balance against shipping documents. It is negotiable.
Q: How to deliver your products to me?
A: We recommend DHL Express for samples and small quantities. It is very fast, safe and relatively cheap. b) We arrange shipment by sea and by air and go with FOB/CIF/CFR terms for large quantities.
Q: What information you need if you need a recommendation on motor?
A: We need to know the basic specifications of a motor: dimensions, rated voltage, speed at load/no load, load/stall torque. If you have no idea whatsoever, you can also a) send me a sample, we can test it and find them out. b) tell me what is your application and describe specifically how it works.
Q: When can I talk to you?
A: Whenever you find me online. Leave me a message or email me if I am offline or I don’t response in 5 minutes.
