20mm PMDC Reduction Gear Motor
Model No. : DSD-20RS180
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 1000pcs
Typical applications: auto shutter, binding machine, automatic TV rack, money counter, spot light, tissue machine, office equipments,household appliances, automatic actuator...
|
|
|
 |
|
 |
|
| |
|
-
DSD-20RS180 20mm PMDC Reduction Gear Motor
-
-
Drawing (mm)
-
 -
Remark: find the length of gearbox "L" in below Technical Data of Gearbox.
-
-
Specifications
Specifications below are for reference only. Contact us for more.
-
| Model Number |
Rated Volt. |
No Load |
At Max Efficiency |
Stall |
| Speed |
Current |
Speed |
Current |
Torque |
Power |
Current |
Torque |
| rpm |
mA |
rpm |
mA |
Kgf.cm |
W |
mA |
Kgf.cm |
| DSD-20RS1800066000-316K |
6V |
19 |
≤150 |
14 |
≤450 |
2.6 |
0.37 |
≥780 |
9 |
| DSD-20RS18001211000-55K |
12V |
200 |
≤150 |
159 |
≤400 |
0.8 |
1.31 |
≥1150 |
3.8 |
| DSD-20RS1800124000-316K |
12V |
12 |
≤45 |
8.5 |
≤110 |
2 |
0.17 |
≥200 |
7.3 |
| DSD-20RS1800123000-316K |
12V |
9 |
≤40 |
5.5 |
≤60 |
1.8 |
0.10 |
≥90 |
4.9 |
| DSD-20RS1800128000-316K |
12V |
25 |
≤80 |
21 |
≤300 |
2.6 |
0.56 |
≥750 |
11 |
| DSD-20RS1800128000-484K |
12V |
16.5 |
≤100 |
12 |
≤300 |
3 |
0.37 |
≥550 |
12 |
| DSD-20RS1800128000-758K |
12V |
10.5 |
≤80 |
8 |
≤350 |
6 |
0.49 |
≥760 |
25 |
| DSD-20RS1800123500-758K |
12V |
4 |
≤25 |
2.9 |
≤70 |
2.4 |
0.07 |
≥120 |
7 |
| DSD-20RS18001816500-132K |
18V |
125 |
≤150 |
105 |
≤550 |
2 |
2.16 |
≥2050 |
11 |
| DSD-20RS1800249500-316K |
24V |
30 |
≤75 |
22 |
≤200 |
3.6 |
0.81 |
≥420 |
14.6 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in |
-
-
What a Model Number Tells You?
-
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
-
 -
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.
-
-
Technical Data of Gearbox
-
| Reduction Stage |
4 |
5 |
6 |
7 |
8 |
| Reduction Ratio |
18K, 23K |
35K, 44K, 55K |
67K, 84K, 105K, 132K |
161K, 202K, 252K, 316K |
386K, 484K, 606K, 758K |
| Length of Gearbox "L" mm |
16.2 |
17.7 |
19.2 |
20.7 |
22.2 |
| Gearbox Efficiency |
65% |
59% |
53% |
48% |
43% |
-
-
Technical Data of Motor
-
| Motor model |
Rated Volt. |
No load |
Load |
Stall |
| Current |
Speed |
Current |
Speed |
Torque |
power |
Torque |
Current |
| V |
mA |
rpm |
mA |
rpm |
gf.cm |
W |
gf.cm |
mA |
| DSD-1800055000 |
5 |
≤75 |
5000 |
≤158 |
4000 |
19 |
0.8 |
≥85 |
≥790 |
| DSD-1800128000 |
12 |
≤35 |
8000 |
≤300 |
6200 |
26 |
1.69 |
≥104 |
≥770 |
| DSD-1800249000 |
24 |
≤36 |
9000 |
≤120 |
7600 |
15 |
1.17 |
≥86 |
≥470 |
-
-
DIY with Your Gear Motor
-
With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.
-
-
Learn More About us:
1.Our main products: Dia12~52mm DC Micro Motor and Gear Motor
Auto dc motor, Electric motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Planetary Gear Motor, Worm Gear Motor etc.
2. Products size range: Diameter:6-52mm
3. DC Voltage range:1.5V-42V
4.Speed range:1RPM-30,000RPM
5.Stall torque:5g.cm-300kg.cm
6. Application: Home appliance, Power Tools, Toys & Model, Precision Instrument, Office equipment, Personal care product, Automotive, Audio&Visual equipment etc.
-
|
|
|
|
|
|
|
