775 High Power High Torque Electric DC Motor

775 High Power High Torque Electric DC Motor
Model No. : DSD-775
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 1000pcs...

PDF Download


775 High Power High Torque Electric DC Motor



Drawing (mm)



Specifications

Specifications below are for reference only. Contact us for more.

Model Number Rated Volt. No Load At Max Efficiency Stall
Current Speed Current Speed Torque Output Torque Current
mA rpm mA rpm gf.cm W gf.cm mA
DSD-775-012-3000 12V 220 3000 1000 2200 350 7.7 1400 3500
DSD-775-012-4250 12V 450 4250 2350 3660 599 22.3 4200 14300
DSD-775-012-4500 12V 450 4500 2000 3300 500 16.5 2000 6500
DSD-775-012-6000 12V 900 6000 4000 4500 750 34.0 3000 13000
DSD-775-024-3000 24V 110 3000 500 2200 350 7.7 1400 1800
DSD-775-024-4260 24V 260 4260 1250 3480 530 18.9 2892 6100
DSD-775-024-4500 24V 230 4500 1000 3300 500 16.5 2000 3300
DSD-775-024-6000 24V 450 6000 2000 4500 750 34.0 3000 7000
DSD-775-024-1200, 0 24V 850 12000 8000 10000 1000 102.6 5600 35000
Remark: 1 gf.cm0.098 mN.m0.014 oz.in    1 mm0.039 in



FAQ
Q: Can you make a motor with custom specifications?
A: Yes, actually that is what we do most of the time.
Q: What is delivery time of samples?
A: 1~3 weeks.
Q: What is delivery time of mass production?
A: 4~5 weeks.
Q: What is the MOQ (minimum order quantity)?
A: You can find it in the front of the product pages.
Q: Do you have motors in stock?
A: No, we don’t. All motors are made with orders.
Q: How much does a motor cost?
A: Please send us an inquiry and tell us exactly what you are looking for.
Q: Do you have quality control?
A: Yes, we have a professional QC team.
Q: Are you a real factory?
A: Yes, we are.
Q: How to pay you?
A: a) We prefer PayPal transfer for samples and small amount of money. b) Bank transfer for large amount of money. Regular payment terms: 30% deposit, balance before shipment / against shipping documents.
Q: How do you handle shipment?
A: We recommend DHL Express for samples and small quantities. It is very fast, safe and relatively cheap. b) We arrange shipment by sea and by air and go with FOB/CIF/CFR terms for large quantities.
Q: What do you need to know if I need a recommendation on motor?
A: Normally we need to know dimensions, rated voltage, speed at load/no load, torque at load/stall. i.e. a motor with diameter 37mm, 12V, 100rpm and 2Kgf.cm at load.
Q: Can I ask you for help if I know nothing about motor?
A: Yes, our pleasure. We are nice people with big hearts.
Q: Can I call you?
A: Yes, please call the international sales manager. He’s very good at English.
Available on 9:00 a.m. ~ 10:00 p.m. China time
