24v right angle dc worm gearmotor 3rpm

24v right angle dc worm gearmotor 3rpm
Model No. : DSD-70SW31ZY
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 300pcs
Typical applications: vending Machine, electrical valve, automatic doors, card conveyors, automatic chemical and oil valve, automatic actuator...
PDF Download
24v right angle dc worm gearmotor 3rpm
Drawing (mm)
Specifications below are for reference only. Contact us for more.
Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
DSD-70SW31ZY0128000-1624K 12V 5 520 3.8 1950 65 2.53 5000 410
DSD-70SW31ZY02410500-177K 24V 59 500 48 2000 12.6 6.21 5100 58
DSD-70SW31ZY0248000-1624K 24V 5 500 3 1700 120 3.69 2500 220
Remark: 1 Kgf.cm0.098 N.m14 oz.in    1 mm0.039 in
What a Model Number Tells You?
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.
Technical Data of Gearbox
Reduction Stage 4 5
Reduction Ratio 177K, 306K, 361K, 423K 492K, 641K, 846K, 1145K, 1624K
Gearbox Efficiency 65% 59%
Technical Data of Motor
Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA rpm mA rpm gf.cm W gf.cm mA
DSD-31ZY0125500 12 180 5500 750 4100 130 5.5 520 3500
DSD-31ZY0127000 12 250 7000 1300 5200 200 10.9 760 5000
DSD-31ZY0129000 12 300 9000 1500 6700 300 21.0 1200 6500
DSD-31ZY0243500 24 100 3500 220 2600 90 2.5 360 850
DSD-31ZY0245500 24 160 5500 320 4100 130 5.6 520 1700
DIY with Your Gear Motor
With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.

Learn More About us:

1.Our main products: Dia12~52mm DC Micro Motor and Gear Motor

Auto dc motor, Electric motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Planetary Gear Motor, Worm Gear Motor etc.

2Products size rangeDiameter:6-52mm

3DC Voltage range:1.5V-42V

4.Speed range:1RPM-30,000RPM

5.Stall torque:5g.cm-300kg.cm

6Application: Home appliance, Power Tools, Toys & Model, Precision Instrument, Office equipment, Personal care product, Automotive, Audio&Visual equipment etc.
