12V 70mm household appliances DC reduction gearbox

 12V 70mm household appliances DC reduction gearbox
Model No. : DSD-70SS3540
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 1000pcs
Typical applications: Labal printers、auto shutter、automatic stabilized voltage supply、grill、oven、cleaning machine、garbage disposers、household appliances、slot machines、money detector、 automatic actuator、coffee machine、towel disposal、lighting、coin refund devices、peristaltic pump....

PDF Download


12V 70mm household appliances DC reduction gearbox



Drawing (mm)



Specifications

Specifications below are for reference only. Contact us for more.

Model Number Rated Volt. No Load At Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
DSD-70SS35400129500-563K 12V 16 340 11 1320 31 3.5 2800 128
Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in    1 mm≈0.039 in



What a Model Number Tells You?

We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.

So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.



Technical Data of Gearbox

Reduction Stage 3 4 5
Reduction Ratio 54K, 73K 217K, 293K 564K, 763K
Length of Gearbox "L" mm 15 15 15
Gearbox Efficiency 73% 65% 59%



Technical Data of Motor

Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA r/min mA r/min gf.cm W gf.cm mA
DSD-35400124500 12 ≤50 4500 ≤420 3600 96 3.62 ≥410 ≥1790
DSD-35400126000 12 ≤59 6000 ≤513 5100 100 5.34 ≥430 ≥2180
DSD-35400244500 24 ≤45 4500 ≤215 3600 97 3.66 ≥410 ≥910
DSD-35400246000 24 ≤42 6000 ≤305 4800 110 5.5 ≥470 ≥1300
DSD-35400247000 24 ≤38 7000 ≤411 5100 115 6.14 ≥490 ≥1750



DIY with Your Gear Motor

With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.

FAQ
Q: Can you make a motor with custom specifications?
A: Yes, actually that is what we do most of the time.
Q: What is delivery time of samples?
A: 1~3 weeks.
Q: What is delivery time of mass production?
A: 4~5 weeks.
Q: What is the MOQ (minimum order quantity)?
A: You can find it in the front of the product pages.
Q: Do you have motors in stock?
A: No, we don’t. All motors are made with orders.
Q: How much does a motor cost?
A: Please send us an inquiry and tell us exactly what you are looking for.
Q: Do you have quality control?
A: Yes, we have a professional QC team.
Q: Are you a real factory?
A: Yes, we are.
Q: How to pay you?
A: a) We prefer PayPal transfer for samples and small amount of money. b) Bank transfer for large amount of money. Regular payment terms: 30% deposit, balance before shipment / against shipping documents.
Q: How do you handle shipment?
A: We recommend DHL Express for samples and small quantities. It is very fast, safe and relatively cheap. b) We arrange shipment by sea and by air and go with FOB/CIF/CFR terms for large quantities.
Q: What do you need to know if I need a recommendation on motor?
A: Normally we need to know dimensions, rated voltage, speed at load/no load, torque at load/stall. i.e. a motor with diameter 37mm, 12V, 100rpm and 2Kgf.cm at load.
Q: Can I ask you for help if I know nothing about motor?
A: Yes, our pleasure. We are nice people with big hearts.
Q: Can I call you?
A: Yes, please call the international sales manager. He’s very good at English.
Available on 9:00 a.m. ~ 10:00 p.m. China time

Contact infromation:
