6V massage vibration micro dc motor

6V massage vibration micro dc motor
Model No. : DSD-49OS500
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 300pcs
Typical applications: optical equipment, CCTV camera, electric lock, automatic bath necessities, water IC Card, toys and gifts, office equipments, household appliances, automatic actuator...

PDF Download


6V massage vibration micro dc motor

Product Description




JS-50 2.jpg

Remark: find the length of gearbox "L" in below Technical Data of Gearbox.



Specifications

Specifications below are for reference only. Contact us for more.

Model Number Rated Volt. No   Load At   Max Efficiency Stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
DSD-49OS5000063200-176K 6V 18 100 11 220 2.6 1.32W 420 8Min
DSD-49OS5000123600-723K 12V 5 8 3 25 3 0.3W 45 8Min
DSD-49OS5000125000-78K 12V 64 80 51 150 0.9 1.8w 550 3.8Min


Remark: 1 Kgf.cm≈0.098   N.m≈14 oz.in   1 mm≈0.039 in



What a Model Number Tells You?

We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.

So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.



Technical Data of Driving Motor

Model

#500

Rated Voltage

6V,8V,9V,12V, 24V

Regular No Load Speed

3000rpm,4500rpm,6000rpm,8000rpm,9000rpm,12000rpm

Rated Power (for reference only)

0.1W~2W



DIY with Your Gear Motor

With the data of the driving motor and the gearbox, now you are ready to DIY with your gear motor. Follow the flowing chart here.
