16mm 3V 6V Low rpm DC Planetary Gear Micro curtain motor

 16mm 3V 6V Low rpm DC Planetary Gear Micro curtain motor
Model No. : DSD-16RP050
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 500pcs
Typical applications: optical equipment, CCTV camera, electric lock, automatic bath necessities, water IC Card, toys and gifts, office equipments, household appliances, automatic actuator...

PDF Download

16mm 3V 6V Low rpm DC Planetary Gear Micro curtain motor

Drawing (mm)
Remark: find the length of gearbox "L" in below Technical Data of Gearbox.

Specifications
Specifications below are for reference only. Contact us for more.
Model Number Rated Volt. No Load At Max Efficiency stall
Speed Current Speed Current Torque Power Current Torque
rpm mA rpm mA Kgf.cm W mA Kgf.cm
DSD-16RP05000313000-22.6K 3V 575 ≤400 393 ≤900 0.2 0.81 ≥1700 ≥0.6
DSD-16RP0500032500-107K 3V 23 ≤42 12 ≤70 0.2 0.02 ≥100 ≥0.5
DSD-16RP0500059000-107K 5V 84 ≤150 56 ≤350 0.78 0.45 ≥630 ≥220
DSD-16RP0500068000-16K 6V 500 ≤120 375 ≤300 0.09 0.35 ≥750 ≥0.4
DSD-16RP0500068000-22.5K 6V 355 ≤120 225 ≤243 0.18 0.42 ≥570 ≥0.55
DSD-16RP0500066000-107K 6V 56 ≤60 42 ≤85 0.14 0.06 ≥380 ≥1.9
DSD-16R P0500068000-2418K 6V 3 ≤80 1.8 ≤140 3.2 0.06 ≥220 ≥7.5
DSD-16RP05001220000-16K 12V 1250 ≤100 937 ≤160 0.15 1.44 ≥600 ≥0.6
DSD-16RP05001217900-107K 12V 167 ≤120 125 ≤480 1.3 1.67 ≥1150 ≥4.8
DSD-16RP05001217900-256K 12V 70 ≤160 52.5 ≤650 3.2 1.72 ≥1300 ≥12
DSD-16RP05001217900-304K 12V 59 ≤150 46 ≤600 3.1 1.46 ≥1350 ≥13
DSD-16RP05001217900-428K 12V 41.7 ≤160 32 ≤600 3.2 1.05 ≥1200 ≥12
DSD-16RP05001217900-509K 12V 35 ≤200 26 ≤700 5 1.33 ≥1150 ≥18
DSD-16RP05001217900-2418K 12V 7.4 ≤165 5.6 ≤450 10 0.57 ≥1150 ≥31
DSD-16RP05001215000-256K 12V 60 ≤200 39 ≤285 2 0.80 ≥750 ≥8
DSD-16RP05001214000-256K 12V 55 ≤150 39 ≤210 1.3 0.52 ≥600 ≥5.2
DSD-16RP0500129000-428K 12V 21 ≤60 14 ≤150 1.6 0.23 ≥260 ≥5.2
DSD-16RP0500128000-256K 12V 31 ≤55 19 ≤135 1 0.19 ≥170 ≥3.2
DSD-16RP0500128000-2418K 12V 3.3 ≤70 1.8 ≤120 3.5 0.06 ≥100 ≥7
Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in    1 mm≈0.039 in

What a Model Number Tells You?
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.

Technical Data of Gearbox
Reduction Stage 1 2 3 4 5
Reduction Ratio 4K, 4.75K 16K, 19K, 22.5K 64K, 76K, 90K, 107K 256K, 304K, 361K, 428K, 509K 1024K, 1216K, 1444K, 1714K, 2036K, 2418K
Length of Gearbox "L" mm 15.8 15.8 19.4 23 26.6
Gearbox Efficiency 90% 81% 73% 65% 59%

Technical Data of Motor
, ,
Motor model Rated Volt. No load Load Stall
Current Speed Current Speed Torque power Torque Current
V mA rpm mA rpm gf.cm W gf.cm mA
DSD-0500068000 6 ≤65 8000 ≤200 6500 7.5 0.50 ≥36 ≥500
DSD-05000612000 6 ≤75 12000 ≤300 9300 10 0.97 ≥40 ≥1000
DSD-0500098000 9 ≤50 8000 ≤150 6500 7 0.47 ≥33 ≥360
DSD-0500128000 12 ≤35 8000 ≤110 6500 6.5 0.44 ≥31 ≥170
DSD-05001217900 12 ≤68 17900 ≤300 12800 12 1.58 ≥54 ≥1260


DIY with Your Gear Motor
With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.


Learn More About us:

1.Our main products: Dia12~52mm DC Micro Motor and Gear Motor

Auto dc motor, Electric motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Planetary Gear Motor, Worm Gear Motor etc.

2. Products size range: Diameter:6-52mm

3. DC Voltage range:1.5V-42V

4.Speed range:1RPM-30,000RPM

5.Stall torque:5g.cm-300kg.cm

6. Application: Home appliance, Power Tools, Toys & Model, Precision Instrument, Office equipment, Personal care product, Automotive, Audio&Visual equipment etc.
