DC flat gearbox motor
Model No. : DSD-95SS3540
Trade Terms: EXW, FOB, CIF, CFR
Port: Shenzhen/Hong Kong
Payment Terms: T/T, PayPal
Minimum Order Quantity: 1000pcs
Typical applications: Pan/TiltCamera、auto shutter、welding machines、water meter IC card、grill、oven、cleaning machine、garbage disposers household appliances、slot machines、money detector、 automatic actuator.coffee machine 、towel disposal、coin refund devices、peristaltic pump、 Lighting stage lamp ....
|
|
|
 |
|
 |
|
| |
|
-
DSD-95SS3540 DC flat gearbox motor
-
-
Drawing (mm)
-
 -
Specifications
-
Specifications below are for reference only. Contact us for more.
-
| Model Number |
Rated Volt. |
No Load |
At Max Efficiency |
Stall |
| Speed |
Current |
Speed |
Current |
Torque |
Power |
Current |
Torque |
| rpm |
mA |
rpm |
mA |
Kgf.cm |
W |
mA |
Kgf.cm |
| DSD-95SS35400124500-94K |
12V |
48 |
≤150 |
35 |
≤800 |
9 |
3.23 |
/ |
/ |
| DSD-95SS35400128000-196K |
12V |
40 |
≤240 |
30 |
≤1400 |
16 |
4.93 |
/ |
/ |
| DSD-95SS35400247000-94K |
24V |
74 |
≤350 |
44 |
≤1000 |
10 |
4.52 |
≥1500 |
≥32 |
| DSD-95SS35400247000-394K |
24V |
17 |
≤150 |
13 |
≤550 |
30 |
4.00 |
≥2400 |
≥100 |
| DSD-95SS35400246000-1166K |
24V |
5.1 |
≤80 |
4.1 |
≤500 |
70 |
2.95 |
≥1150 |
≥300 |
| Remark: 1 Kgf.cm≈0.098 N.m≈14 oz.in 1 mm≈0.039 in |
-
-
What a Model Number Tells You?
-
We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.
-
-
So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷ reduction ratio 100 = 60rpm.
-
-
Technical Data of Gearbox
-
| Reduction Stage |
3 |
4 |
5 |
| Reduction Ratio |
94K |
394K |
1166K |
| Length of Gearbox "L" mm |
16 |
16 |
16 |
| Gearbox Efficiency |
73% |
65% |
59% |
-
-
Technical Data of Motor
-
| Motor model |
Rated Volt. |
No load |
Load |
Stall |
| Current |
Speed |
Current |
Speed |
Torque |
power |
Torque |
Current |
| V |
mA |
rpm |
mA |
rpm |
gf.cm |
W |
gf.cm |
mA |
| DSD-35400124500 |
12 |
≤50 |
4500 |
≤420 |
3600 |
96 |
3.62 |
≥430 |
≥1790 |
| DSD-35400126000 |
12 |
≤59 |
6000 |
≤513 |
5100 |
100 |
5.34 |
≥600 |
≥2180 |
| DSD-35400244500 |
24 |
≤45 |
4500 |
≤215 |
3600 |
97 |
3.66 |
≥436 |
≥910 |
| DSD-35400247000 |
24 |
≤38 |
7000 |
≤411 |
5100 |
115 |
6.14 |
≥380 |
≥1750 |
-
-
DIY with Your Gear Motor
-
With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.
-
-
-
|
|
|
|
|
|
|
